        TSR-310

        Handheld Touch Screen Remote

        An elegant, ergonomic, and rugged handheld remote with 3” color touch screen, backlit buttons, voice control capability, and enhanced Wi-Fi® wireless communications. Movement sensing wakes the remote the instant it’s picked up so it’s always ready to use.

        Click here for a list of Crestron® certified Wi-Fi wireless access points.

        The Crestron® TSR-310 Handheld Touch Screen Remote is an elegant, customizable wireless controller designed for use in home theaters, bedrooms, hotel rooms, boardrooms, and many other applications. Ruggedized for durability, the TSR-310 offers exceptional comfort and ergonomics for hours of one-handed use. Its backlit buttons provide positive tactile response and clear visibility under all lighting conditions. Its high-resolution 3” (76 mm) capacitive touch screen affords completely customizable control over audio, video, lighting, shades, climate, security, and other amenities. Built-in Voice Recognition allows many functions to be executed using spoken commands. Dependable wireless performance is ensured using enhanced Wi-Fi® technology. A space-saving tabletop dock is included for charging the remote.[1]

        Backlit Tactile Buttons
        A full complement of buttons provides immediate access to everything you need to watch TV, listen to music, navigate onscreen menus, and browse through media titles on your TV display. Each button is clearly labeled using familiar text and icons for intuitive operation. Button backlighting affords excellent legibility in darkened rooms. The 5-way thumbpad affords easy directional navigation in normal use and changes colors when placed in four-color mode to provide access to the green, blue, red, and yellow option buttons.

        Each button on the TSR-310 is fully programmable to deliver precise and predictable behavior, whether simply adjusting audio volume and flipping through channels, browsing a media library or program guide, controlling a DVR or DVD player, or operating a pan/tilt camera.

        Touch Screen with Smart Graphics®
        The TSR-310 features a high-resolution, high-contrast capacitive touch screen to enable fully customizable control over anything in your home or workplace. Crestron Smart Graphics technology delivers an engaging and intuitive touch screen experience with fluid gesture-driven controls, kinetic effects, animated feedback, rich metadata, embedded apps and widgets, and personalized themes – all custom tailored to your needs.

        Scrolling menus of channel presets and media titles appear on the touch screen with full color icons and cover art for easy access to all your favorite TV channels, radio stations, movies, and music. Actual lighting levels, shade positions, room temperature, door lock status, and security system status are graphically displayed and adjustable with a simple finger stroke. Even weather conditions and other useful information can be viewed without reaching for your smartphone.[1]

        Voice Command Recognition
        Some things are easier said than done, so why not just say what you want and let Crestron do it for you? With built-in voice recognition, the TSR-310 provides the ability to use spoken commands to control a variety of devices and functions. Voice recognition can be used to quickly turn devices on or off, change the channel, choose a lighting scene, lower the windows shades, lock the doors, or arm the security system. Simply press the Voice button and say a command and Crestron does the rest.[1,2]

        Movement Sensor
        Its built-in accelerometer wakes the TSR-310 instantly whenever it’s picked up or moved, so it’s always ready for use.

        Instant-Waking®
        Even without picking it up, the TSR-310 wakes instantly at the press of a button and transmits the button press within milliseconds. So spontaneous actions like muting the audio, pausing the video, or changing the channel can be executed on the fly, even with the remote left lying on an armrest or placed in its charging dock.

        Auto-Brightness Control
        To ensure optimal visibility under varying lighting conditions, the TSR-310 includes a built-in light sensor, which regulates the brightness of the touch screen display and button backlighting according to the ambient light level in the room.

        Advanced Wi-Fi® Wireless Performance
        Crestron enhanced Wi-Fi performance is optimized to deliver fast, dependable wireless communications with a remarkable 50 feet (15 meters) omnidirectional range (conditions permitting). The choice of 802.11 a, b, g, and n protocols affords reliable, high-speed wireless connectivity in virtually any RF environment. For Wi-Fi networks with multiple access points, the TSR-310 supports the ability to hand off communication from one access point to another if the active connection is lost.[3]

        Note: The TSR-310 has been tested and verified to work with wireless access points from a variety of leading manufacturers. Please visit https://www.crestron.com/Products/Featured-Solutions/TSR-310-with-Wi-Fi for a list of recommended WAP manufacturers.

        Extended Battery Life
        To conserve power, the TSR-310 goes into a sleep state when not in use. In sleep mode, the TSR-310 maintains a very low level connection to the wireless access point, ensuring instantaneous response upon waking. Maximum battery life and performance are ensured only when using a Crestron certified wireless access point (see above). Under typical use, the TSR-310 can operate continuously for 5.5 hours between charges.

        Table Dock Charger
        Its included table dock provides for charging the TSR-310 while occupying minimal space on the tabletop or shelf. When placed on the table dock, the remote remains upright and fully operational while charging.[4]


        Key Features
        • Customizable handheld wireless remote
        • Elegant, ergonomic, and rugged design
        • 3" (76 mm) HVGA capacitive color touch screen with Smart Graphics®
        • Backlit buttons for AV/DVR control and OSM navigation
        • 5-way navigation pad changes colors when accessing the four-color buttons mode
        • Voice recognition executes functions using spoken commands [2]
        • Fully programmable functionality via a Crestron® control system [1]
        • Advanced, high-performance Wi-Fi® wireless communications [3]
        • Movement sensor wakes the remote when picked up
        • Instant-Waking® executes button presses without picking up
        • Auto-brightness control maintains optimal visibility
        • Setup and diagnostics via touch screen or web browser
        • Li-Polymer rechargeable battery
        • Space-saving table dock charger [4]
        1. A complete Crestron control system, plus additional equipment and services, are required to deliver all the capabilities and functionality described. Please contact your Crestron representative to learn more.
        2. Voice recognition, weather information, and certain other functions require an Internet connection.
        3. Refer to https://www.crestron.com/Products/Featured-Solutions/TSR-310-with-Wi-Fi for a list of recommended wireless access points.Wi-Fi “handoff” capability enables automatic handoff amongst up to four pre-designated Wi-Fi wireless access points, wherein the last successful Wi-Fi connection is maintained indefinitely until that connection is lost, at which point communication is handed off to the next nearest access point. A very brief interruption to wireless Ethernet communication may occur during the handoff.
        4. The TSR-310 ships with (1) TSR-310-DS Table Dock included. Additional docks may be ordered separately. Refer to the TSR-310-DS spec sheet for additional information.



        This product may be purchased from an authorized Crestron dealer. To find a dealer, please contact the Crestron sales representative for your area. A list of sales representatives is available online at https://www.crestron.com/How-To-Buy/Find-a-Representative or by calling 855-263-8754.

        The specific patents that cover this and other Crestron products are listed online at https://www.crestron.com/legal/patents.

        Certain Crestron products contain open source software. For specific information, visit https://www.crestron.com/opensource.

        Crestron, the Crestron logo, Instant-Waking, and Smart Graphics are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Wi-Fi is either a trademark or registered trademark of Wi-Fi Alliance in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography. Specifications are subject to change without notice. ©2018 Crestron Electronics, Inc.



        Note: See also TSR-310-DS for additional specifications.

        Touch Screen Display
        Display Type TFT Active matrix color LCD
        Size 3 inch (76 mm) diagonal
        Aspect Ratio 3:2 HVGA (portrait orientation)
        Resolution 320 x 480 pixels
        Brightness 410 nits (cd/m²) typical
        Contrast 700:1 typical
        Color Depth 18-bit, 262,144 colors
        Viewing Angle ±80° horizontal, ±80° vertical
        Illumination LED Backlit w/auto-brightness control (adjustable high, medium, and low settings)
        Touch Screen Projected capacitive, 3-point multi-touch capable
        Note: Pressing any button or moving the remote wakes the remote from sleep mode; a second button press or touching the touch screen wakes the touch screen display (configurable for any button or just Power, Voice, and Home); the touch screen display may also be configured to wake on movement.
        Buttons
        Power (1) Programmable pushbutton with red power icon
        Voice (1) Pushbutton with microphone icon, initiates voice command capture [2]
        Home (1) Programmable pushbutton with list icon
        Functions (8) Programmable pushbuttons with text or icons for volume up, volume down, mute, guide, menu, up, down, and info
        Navigation Pad (1) Programmable 5-way directional navigation pad for up, down, left, right, and select; alternately functions as four context-dependent option buttons when the ‘four color mode’ button is pressed (nav pad icons illuminate green, blue, red, and yellow in this mode)
        Transport (11) Programmable pushbuttons with text or icons for exit, last, rewind, play, forward, previous, pause, next, stop, DVR, and record
        Illumination White LED backlighting behind all button labels w/auto-brightness control (adjustable high, medium, and low settings)
        Note: Pressing any button or moving the remote wakes the remote from sleep mode and turns on the button backlight if the room is dark
        Light Sensor
        Photosensor detects the ambient light level to enable the button backlight if the room is dark and automatically adjust the touch screen display and button backlight brightness
        Movement Sensor
        Accelerometer detects if the remote is picked up or moved, wakes the remote from sleep mode, and turns on the button backlight if the room is dark; may also wake the touch screen display if desired
        Graphics
        Graphics Engine Crestron Smart Graphics, on-screen numeric keypad and multi-language keyboard, screensaver
        Maximum Project Size 512 MB
        Languages
        Smart Graphics Arabic, Chinese (Simplified), Chinese (Traditional), Czech, Danish, Dutch, English (UK), English (US), Finnish, French, German, Greek, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Portuguese (Brazilian), Romanian, Russian, Slovak, Spanish, Swedish, Thai
        On-Screen Keyboard Arabic, Chinese (Simplified), Croatian, Czech, Danish, Dutch, English (UK), English (US), Finnish, French (Canada), French (Switzerland), German, Hebrew, Hungarian, Italian, Japanese, Norwegian Bokmal, Polish, Portuguese, Russian, Serbian, Spanish, Swedish, Turkish
        Voice Recognition Afrikaans (South Africa); Chinese, Mandarin (China, Simplified); Chinese, Mandarin (Hong Kong, Simplified); Chinese, Mandarin (Taiwan, Traditional); Chinese, Yue (Hong Kong, Traditional); Czech (Czech Republic); Dutch (Netherlands); English (Australia); English (Canada); English (Generic); English (India); English (New Zealand); English (South Africa); English (UK); English (US); French (France); German (Germany); isiZulu (South Africa); Italian (Italy); Japanese (Japan); Korean (South Korea); Polish (Poland); Portuguese (Brazil); Russian (Russia); Spanish (Spain); Turkish (Turkey)
        Wireless Communication
        Transceiver IEEE 802.11a/b/g/n Wi-Fi (2.4 or 5 GHz 2-way RF), static IP or dynamic IP via DHCP [3]
        Security 64 & 128-bit WEP, WPA & WPA2-PSK with TKIP & AES
        Range Up to 50 feet (15 m), subject to site-specific conditions
        Handoff Supports handoff between a maximum of four Wi-Fi wireless access points [3]
        Gateway Requires an 802.11a/b/g/n wireless access point and Ethernet-enabled Crestron control system
        Note: The TSR-310 has been tested and verified to work with wireless access points from a variety of leading manufacturers. Please visit https://www.crestron.com/Products/Featured-Solutions/TSR-310-with-Wi-Fi for a list of recommended WAP manufacturers.
        Wired Communication
        USB USB client for console only (installer setup)
        Audio
        Features Built-in microphone for multi-language voice recognition [2]
        Connectors
        USB (1) Micro-USB Type B console port behind battery compartment cover, for installer use only
        Charging Contacts (2) Contacts which mate with the charging terminals on the table dock
        Battery
        Rechargeable Battery Li-Polymer, 3.7 Volt, 2000 mAh, model TSR-310-BTP
        Usage per Charge 5.5 hours continuous
        Charging Time 3 hours
        Power
        Power Pack (included) Input: 100-240 Volts AC, 50/60 Hz;
        Output: 2 Amps @ 5 Volts DC
        Note: Power connection made via the charging dock [4]
        Environmental
        Temperature 32° to 104° F (0° to 40° C);
        50° to 104° F (10° to 40° C) while charging
        Humidity 10% to 90% RH (non-condensing)
        Construction
        Ruggedized ABS plastic, black housing, black buttons with backlit laser etched labeling
        Dimensions
        Height 0.95 in (24 mm)
        Width 2.28 in (58 mm)
        Depth 8.68 in (221 mm)
        Weight
        6.35 oz (180 g)
        Compliance
        CE, IC, FCC Part 15 Class B digital device
        1. A complete Crestron control system, plus additional equipment and services, are required to deliver all the capabilities and functionality described. Please contact your Crestron representative to learn more.
        2. Voice recognition, weather information, and certain other functions require an Internet connection.
        3. Refer to https://www.crestron.com/Products/Featured-Solutions/TSR-310-with-Wi-Fi for a list of recommended wireless access points.Wi-Fi “handoff” capability enables automatic handoff amongst up to four pre-designated Wi-Fi wireless access points, wherein the last successful Wi-Fi connection is maintained indefinitely until that connection is lost, at which point communication is handed off to the next nearest access point. A very brief interruption to wireless Ethernet communication may occur during the handoff.
        4. The TSR-310 ships with (1) TSR-310-DS Table Dock included. Additional docks may be ordered separately. Refer to the TSR-310-DS spec sheet for additional information.



        This product may be purchased from an authorized Crestron dealer. To find a dealer, please contact the Crestron sales representative for your area. A list of sales representatives is available online at https://www.crestron.com/How-To-Buy/Find-a-Representative or by calling 855-263-8754.

        The specific patents that cover this and other Crestron products are listed online at https://www.crestron.com/legal/patents.

        Certain Crestron products contain open source software. For specific information, visit https://www.crestron.com/opensource.

        Crestron, the Crestron logo, Instant-Waking, and Smart Graphics are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Wi-Fi is either a trademark or registered trademark of Wi-Fi Alliance in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography. Specifications are subject to change without notice. ©2018 Crestron Electronics, Inc.
